AAA TRAILERS SIDE TIPPER LEAD (A)

AAA Trailers is proudly Australian owned and operated.

Additional info:

• This unit comes with a 12-month warranty.
• Pre- and post-sales service available.
• We have locations across Australia, including Sydney, Perth, Adelaide, Melbourne, and Brisbane.
• Additional charges will apply if you require trailer registration and transportation.

Specifications

Bowl: 5000mm, Capacity 17m3

Length: Overall Length 9.94mt, Width 2500mm, Height 3089mm

Capacity (ATM): 45-47 tonnes

Capacity (GTM): 20-23.5 tonnes

Tare Weight: 8.8 tonnes (Roll Tarp) / 9.1 tonnes (Hydraulic Lid)

Brakes: K- Hitch drum brake American 10 studs hubs

Coupling: 50mm or 90mm single position bolt in K-Hitch king pin

Suspension: FUWA K-Hitch FW52U 8 leaf spring suspension, 11-tonne rated K-Hitch axle

K-Hitch Turntable: 90mm or 50mm

Warranty: 12 months

Tyres: 11R22.5 on American 10 Stud Alloy Rims

Spare Available: 1 spare tyre included

Accessories:

• 12-volt roll tarp with cordless remote
• 450 grade high tensile bowl 6mm floors, door, front & rear panel, side panel 4.5mm
• EBS braking system
• 12mm skid plate
• Parallel bearing K-Hitch axles
• LED lights
• Quad road train-rated
• Dual spare wheel holders
• High tensile chassis built for Australian outback conditions
• K-Hitch 2 speed landing legs with compensating feet
• Road train kit & Ringfeder included
• Hydraulic hoses & airline set included

Optional Extras:

• Custom painting
• Automatic greasing system
