Curtainsider Trailers

AAA TRAILERS CURTAINSIDER – STRAIGHT DECK A-TRAILER 12 PALLET

Specifications	Details
Capacity	ATM: 47T GTM: 23.5T Approx tare weight: 7.3T
Length	11.7m
Deck	7.3m
Mainframe	High-tensile steel grade
Floor	5mm steel chequer plate, forklift-rated
Kingpin	Dual-position 50mm bolt-in (90mm optional)
Coaming	C-channel with tie rail
Brake kit	EBS multi-volt 12/24V
Gates	Side gate pockets with hanging aluminium side gates
Axles	K-Hitch 22.5” drum brake axles
Suspension	K-Hitch tri-axle airbag
Landing legs	K-Hitch 2-speed
Wheels	10/285 PCD dual steel rims (aluminium optional)
Tyres	11R22.5
Spare wheel carrier	Dual (spare wheels optional)
Lighting	Full LED
Water tank	30L stainless steel
Toolboxes	1 steel with stainless steel “T” handles
Mudguards	Plastic radius guards with AAA Trailers mudflaps
Curtains	Polyweld load restraint, single base colour
Optional extras	Road Train Kit Ring Feeder Custom Paint - Coaming Rails Road Train / Long Vehicles Signs Hub Odometer Spare Wheel: teel or Alloy Custom Curtains: To be Quoted

Specifications	Details
Capacity	ATM: 47T GTM: 23.5T Approx tare weight: 8.6T
Length	13.8m
Deck	13.2m
Mainframe	High-tensile steel grade
Floor	5mm steel chequer plate, forklift-rated
Kingpin	Dual-position 50mm bolt-in (90mm optional)
Coaming	C-channel with tie rail
Brake kit	EBS multi-volt 12/24V
Gates	Side gate pockets with hanging aluminium side gates
Axles	K-Hitch 22.5” drum brake axles
Suspension	K-Hitch tri-axle airbag (Spring Optional)
Landing legs	K-Hitch 2-speed
Wheels	10/285 PCD dual steel rims (aluminium optional)
Tyres	11R22.5
Spare wheel carrier	Dual (spare wheels optional)
Lighting	Full LED
Water tank	30L stainless steel
Toolboxes	2 steel with stainless steel “T” handles
Mudguards	Plastic radius guards with AAA Trailers mudflaps
Curtains	Polyweld load restraint, single base colour
Optional extras	Road Train Kit Ring Feeder Custom Paint - Coaming Rails Road Train / Long Vehicles Signs Hub Odometer Spare Wheel: teel or Alloy Custom Curtains: To be Quoted

Specifications	Details
Capacity	ATM: 47T GTM: 23.5T Approx tare weight: 8.9T
Length	11.7m
Deck	7.6m
Mainframe	High-tensile steel grade
Floor	5mm steel chequer plate, forklift-rated
Coaming	C-channel with tie rail
Brake kit	EBS multi-volt 12/24V
Gates	Side gate pockets with hanging aluminium side gates
Axles	K-Hitch 22.5” drum brake axles
Suspension	K-Hitch tri-axle airbag
Landing legs	K-Hitch 2-speed
Turntable	K-Hitch 50mm bolt in (90mm optional)
Kingpin	Dual-position 50mm bolt in (90mm optional)
Wheels	10/285 PCD dual steel rims (aluminium optional)
Tyres	11R22.5
Spare wheel carrier	Dual (spare wheels optional)
Lighting	Full LED
Water tank	30L stainless steel
Toolboxes	1 steel with stainless steel “T” handles
Mudguards	Plastic radius guards with AAA Trailers mudflaps
Curtains	Polyweld load restraint, single base colour
Optional extras	Road Train Kit Ring Feeder Custom Paint - Coaming Rails Road Train / Long Vehicles Signs Hub Odometer Spare Wheel: teel or Alloy Custom Curtains: To be Quoted

Specifications	Details
Capacity	ATM: 47T GTM: 23.5T Approx tare weight: 10.5T
Length	13.8m
Mainframe	High-tensile steel grade
Floor	5mm steel chequer plate, forklift-rated
Kingpin	Dual-position 50mm bolt-in (90mm optional)
Coaming	C-channel with tie rail
Brake Kit	EBS multi-volt 12/24V
Gates	Side gate pockets with hanging aluminium side gates
Axles	K-Hitch 22.5” drum brake axles
Suspension	K-Hitch tri-axle airbag
Landing Legs	K-Hitch 2-speed
Wheels	10/285 PCD dual steel rims (aluminium optional)
Tyres	255/70R22.5
Spare Wheel Carrier	Dual (spare wheels optional)
Lighting	Full LED
Water Tank	30L stainless steel
Toolboxes	2 steel with stainless steel “T” handles
Mudguards	Plastic radius guards with AAA Trailers mudflaps
Curtains	Polyweld load restraint, single base colour
Optional Extras	Road Train Kit Ring Feeder Custom Paint - Coaming Rails Road Train / Long Vehicles Signs Hub Odometer Spare Wheel: teel or Alloy Custom Curtains: To be Quoted
